SP 1000 Offset Slipform Paver

Get a Price/Quote

MOQ : 1 Unit

SP 1000 Offset Slipform Paver Specification

Application
Road and highway construction

Rated Power
82 kW

Lifting Height
Up to 500 mm

Max Flow Rate
260 l/min (hydraulic system)

Max Pressure
320 bar (hydraulic)

Motor Power
110 HP

Surface
Paint coated, corrosion resistant

Lifting Speed
Variable, hydraulically controlled

Product Type
Offset Slipform Paver

General Use
Concrete paving for roads, kerbs, and channels

Material
Heavy-duty steel

Capacity
Up to 1000 mm paving width

Weight (kg)
Approx. 18,000 kg

Automatic
Yes

Cooling System
Water cooled, radiator type

Method
Slipform

Voltage
24 V DC (operational system), 230V/415V (auxiliary)

Dimension (L*W*H)
6,500 mm x 2,500 mm x 3,000 mm

Feature
High maneuverability, compact design

Color
Yellow and Blue

Steering System
Four-way hydraulic

Gradeability
Up to 20%

Travel Speed
0 - 12 km/h

Operator Cabin
Ergonomic, with easy-access controls

Fuel Tank Capacity
280 L

Noise Level
Less than 80 dB(A) at operator position

Sensor System
Automatic vibrators and screed sensors

Chassis Type
Heavy-duty welded frame

Hydraulic Tank Capacity
350 L

Inclination Adjustment
Electro-hydraulic

Engine Make
Diesel, turbocharged

Water Spray System
Automatic, for slipform and cleaner

Track Type
Rubber coated crawler tracks

Emission Standard
Complies with latest EPA Tier standards

Paving Speed
Up to 5 m/min

SP 1000 Offset Slipform Paver Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
1 Unit Per Month

Delivery Time
1-2 Week

About SP 1000 Offset Slipform Paver

The SP 1000 is a versatile and compact slipform paver engineered for projects that demand high-capacity forming and exceptional maneuverability. Designed by Siddhivinayak Engineering, this model is the ideal solution for constructing specialized concrete structures such as large safety barriers, substantial median strips, and complex drainage channels.

With its advanced electronic guidance system and custom-mould integration, the SP 1000 delivers millimetre-perfect accuracy and a smooth, superior finish, ensuring high productivity on every job site.

Performance Features

Impressive Forming Capacity: Specifically built to handle substantial concrete elements, achieving profiles up to 1,050 mm in height and 1,450 mm in width.
Precision Guidance: Utilizes an advanced electronic sensing system that follows a pre-set string line to control both steering and mould elevation with millimetre-perfect accuracy.
Continuous Material Flow: Equipped with a heavy-duty, fully hydraulic belt conveyor that ensures a non-stop supply of concrete, maximizing laying speed and efficiency.
Optimal Consolidation: Integrated high-frequency vibrators eliminate air voids, maximizing concrete density and strength for long-term structural durability.
Enhanced Maneuverability: The compact design and three-track system provide the stability and gradeability needed for specialized urban and highway applications

Primary Applications

Highway Kerbs & Gutters
Central Verges & Median Barriers
Irrigation Channels & V-Drains

Technical Specifications

SP 1000
Range of Applications	Offset paving
Concrete feeding system
Belt conveyor	Length: 4900 mm; belt width :500 mm
Concrete paving mould
Arrangement	Right
Lateral adjustment of mould	300 mm
Max. mould height	1050 mm
Max. mould width	1450 mm
Vibration
Standard Connectors for hydraulic vibration	6
Engine
Engine manufacturer	Perkins
Type	1100 Series
Cooling	Water
Number of Cylinders	4
Rated power at 2200 rpm	67 kW/ 90 HP
Cubic Capacity	4.4 Litres (269 CU.IN.)
Fuel Consumption, Full load	10 to 11 Litre / Hour
Exhaust emission standards	EU Stage 3a/US Tier 3
Electrical System
Voltage supply	12V
Filling Capacities
Fuel	200 L
Hydraulic oil	210 L
Water	200 L
Cleaning Equipments	Heavy Duty Water Pump
Driving Performance
Operating speed	0 to 5 m/min
Travel speed	0 to 15 m/min
Track units
Number of track units	3
Track unit arrangement	1 x Front / 2 x Rear
Dimensions (L x W x H)	1500 mm x 230 mm x 470 mm
Height Adjustment of Machine
Hydraulic height adjustment	500 mm
Mechanical height adjustment	NO
Transport Dimensions (L x W x H)
Basic machine without concrete feeding system	5800 mm x 2300 mm x 3100 mm
Basic machine with belt conveyor	5800 mm x 3100 mm x 3100 mm
Belt conveyor without chute	4300 mm x 900 mm x 600 mm
Machine Weight
Operating Weight	9160 kg
Belt conveyor	1150 kg

Experience the trending marvel in road construction: the SP 1000 Offset Slipform Paver. Distinguished by its preeminent rubber-coated crawler tracks and incomparable paving width of up to 1000 mm, this automatic offset paver is engineered for high maneuverability and optimal performance. The ergonomic operator cabin, electronic-hydraulic controls, and microprocessor-based system elevate operation excellence. Shop now, as availability is ending soon-secure your concrete paving solution that is both advanced and corrosion resistant, offering seamless offset paving for roads, kerbs, and channels across India.

Versatile Application for Modern Construction

The SP 1000 Offset Slipform Paver is meticulously designed for road and highway construction across diverse terrains. Its direction of use is simple-operate via the ergonomic, easy-access operator cabin and choose between slipform paving for kerbs, channels, or full-width carriageways. This specialized machine excels in general concrete paving and specific tasks requiring precision. Its heavy-duty steel chassis and automatic operation guarantee reliability and efficiency for every project.

Comprehensive Packaging and Global Market Reach

Each SP 1000 Offset Slipform Paver is delivered with reinforced export-grade packaging to ensure transit safety. With a sale price and proposal amount tailored to client requirements, order processing is swift and reliable. This distinguished product is exported globally, with a particular focus on key markets in India. Certifications signify adherence to the latest EPA Tier emission standards, ensuring quality and compliance at every stage.

FAQ's of SP 1000 Offset Slipform Paver:

Q: How does the SP 1000 Offset Slipform Paver enhance paving operations?

A: The paver operates with a computerized, microprocessor-based system for precise control. Its electro-hydraulic inclination adjustment, automatic sensors, and ergonomic operator cabin deliver consistent, high-quality results while simplifying complex concrete paving tasks.

Q: What materials and applications is the SP 1000 suitable for?

A: Constructed from heavy-duty steel and finished in a corrosion-resistant coating, it is tailored for concrete paving in roads, kerbs, and channels. Its robust design makes it ideal for demanding construction sites and varying project requirements.

Q: When is the optimal time to place an order for the SP 1000?

A: It is recommended to act promptly, as inventory is often limited due to high demand. Take advantage of the current sale price and proposal amount for timely order processing and delivery.

Q: Where does the SP 1000 Offset Slipform Paver excel in use?

A: This machine excels on urban and highway projects throughout India and other international markets, where reliability, versatility, and high productivity are required for effective concrete paving.

Q: What is the process for receiving the SP 1000 after purchase?

A: After placing an order, the paver is packaged securely using reinforced materials for export. Clients can expect efficient handling, documentation, and shipping to their specified location, in accordance with international standards.

Q: How does the operator benefit from the SP 1000's features?

A: Operators benefit from reduced noise levels, ergonomic controls, and advanced safety systems, ensuring comfortable operation and increasing overall jobsite productivity.
